RC hydrofoil
Source: Thingiverse by antoinef
The RC hydrofoil is a free printable 3D model from Thingiverse by antoinef. June 2017: News!!! The rudder assembly has been reworked to allow for a change in the pitch angle. You can download the STL file from the original listing below and print it at home.
About this model
June 2017: News!!! The rudder assembly has been reworked to allow for a change in the pitch angle. I mounted to servos and mix them (V-tail program on the transmitter). You need two 624ZZ 4mm x 13mm x 5mm ball bearing. I added a new set of back foils (symmetrical) as well. The boat is much more stable now! I thing that if you don't want to add the relative complexity of a mixing servos, it should work just by setting up the proper angle and fasten it in place. Thanks for your comments and I hope that you guys will build it, it's a great project! July 26th 2015: This is my latest attempt of a RC hydrofoil. The profile is a Naca 63-412 (both front and back foils). The back foil has a 5deg dihedral for lateral stability. It's in two parts, glued together, in order to print the part without su…
Frequently asked questions
- Is this 3D model free to download?
- Yes. RC hydrofoil is free to download from Thingiverse. Open it in the free Thinger app, or use the "Download from Thingiverse" link above to open the original listing.
- Where is the STL hosted?
- The download is hosted by Thingiverse, not by Thinger. We link you directly to the original listing by antoinef.
- Who made this model?
- Designed by antoinef, published on Thingiverse. Please credit the creator when sharing your print online.
- Can I print this at home?
- Yes. This model is intended for home FDM and resin 3D printers. Check the original listing for suggested print settings like layer height and supports.
