CR-10 | CR-10S | BondTech BMG E3D V6 + EZABL Mount V2
Source: Thingiverse by MP23Racing
The CR-10 | CR-10S | BondTech BMG E3D V6 + EZABL Mount V2 is a free printable 3D model from Thingiverse by MP23Racing. UPDATE 2/26/2018 I have designed a 40mm fan mount to accommodate the Noctua 40mm Fan (NF-A4x10 FLX). You can download the STL file from the original listing below and print it at home.
About this model
UPDATE 2/26/2018 I have designed a 40mm fan mount to accommodate the Noctua 40mm Fan (NF-A4x10 FLX). The Noctua fan reduced the ambient noise on the CR-10S from around 49-51 dB to around 39-40 dB. It fits snug enough, but is still free to rotate slightly around the E3D heatsink. I printed this in NylonX for its flexibility, but I believe all materials should work as well, but I have not tested them. Thanks to Sean for the Noctua 40mm fan shroud GrabCAD model and to JuanCR for the E3D V6 GrabCAD model! This new mount assembly was designed to restore full use of the CR-10/CR-10S build area. I was not thrilled with the previous design which eliminated almost 15-20 mm in X and Y so I went back to re-design this unit to fit as close to the stock CR-10 extruder assembly as possible to re-gain th…
Frequently asked questions
- Is this 3D model free to download?
- Yes. CR-10 | CR-10S | BondTech BMG E3D V6 + EZABL Mount V2 is free to download from Thingiverse. Open it in the free Thinger app, or use the "Download from Thingiverse" link above to open the original listing.
- Where is the STL hosted?
- The download is hosted by Thingiverse, not by Thinger. We link you directly to the original listing by MP23Racing.
- Who made this model?
- Designed by MP23Racing, published on Thingiverse. Please credit the creator when sharing your print online.
- Can I print this at home?
- Yes. This model is intended for home FDM and resin 3D printers. Check the original listing for suggested print settings like layer height and supports.
