Drillguide for straight/perpendicular holes Type A1, customizable 3D printable model by Coat

Drillguide for straight/perpendicular holes Type A1, customizable photo 1

Drillguide for straight/perpendicular holes Type A1, customizable photo 2

Drillguide for straight/perpendicular holes Type A1, customizable photo 3

Drillguide for straight/perpendicular holes Type A1, customizable photo 4

Drillguide for straight/perpendicular holes Type A1, customizable

Source: Thingiverse by Coat

The Drillguide for straight/perpendicular holes Type A1, customizable is a free printable 3D model from Thingiverse by Coat. A simple to use drilling-jig for drilling perpendicular/straight holes. You can download the STL file from the original listing below and print it at home.

Open in Thinger (free) Download from Thingiverse

3,794 saves Source: Thingiverse Updated 2026-10-17 License: CC-BY-SA · commercial OK 3 makes Category: Tools & Workshop

Tags: carpintaria, carpintera, customizable, dril, Drill jig, Drillguide, drilling guide, holzbearbeitung, houtbewerking, Jig, parametric, perpendicular, straight holes, travail du bois, woodworking

About this model

A simple to use drilling-jig for drilling perpendicular/straight holes. You can customize the jig so that it "fold" over the edge of a board (see picture). The jig is only usable for 1 drill-diameter. The easiest way to use it: put the jig over your drill, place the drill, put the jig down and flat to the wood without moving the drill point. The "cross" over the jig is for viewing marks and for the removal of sawdust Three examples for 8 mm drill are added as STL (the winged versions are intended for 18 mm board). Remember, it's a guide which will help you, not an assurance that you will drill perpendicular holes :) For two other types of drill-jigs i made see: Drillguide for five drillsizes: Drillguide for all drillsizes: Look for more tools and the like here: Happy woodworking :) Designe…
