Pinewood Derby Axle Drilling Template
Source: Thingiverse by sparticus1701
The Pinewood Derby Axle Drilling Template is a free printable 3D model from Thingiverse by sparticus1701. This is a drilling template for pinewood derby car blocks. You can download the STL file from the original listing below and print it at home.
About this model
This is a drilling template for pinewood derby car blocks. Drilling using a #44 bit is better than using the standard cut slots, which make alignment of the wheels difficult to make and maintain. With this template, you don't have to worry about making mistakes in where the holes are drilled. There are holes for the standard positions, as well as for an extended wheelbase. Just insert the block, drill and remove. On my print the block fits pretty snugly. Depending on your printer you may need to sand the inside a little. The v2 file has wider sides around the holes, which can help with drilling straight. v3 extends the inner dimensions by 1/64". This can compensate for a slightly large block or variations in printers. Thanks to heatvent ( for the suggestion. v4 adds a hole in the middle wh…
Frequently asked questions
- Is this 3D model free to download?
- Yes. Pinewood Derby Axle Drilling Template is free to download from Thingiverse. Click the "Download free STL" button above to open the original listing.
- Where is the STL hosted?
- The download is hosted by Thingiverse, not by Thinger. We link you directly to the original listing by sparticus1701.
- Who made this model?
- Designed by sparticus1701, published on Thingiverse. Please credit the creator when sharing your print online.
- Can I print this at home?
- Yes. This model is intended for home FDM and resin 3D printers. Check the original listing for suggested print settings like layer height and supports.
