Rigol DHO800 Probe Organizer and Vesa Standoff
Source: Thingiverse by The_Herder
The Rigol DHO800 Probe Organizer and Vesa Standoff is a free printable 3D model from Thingiverse by The_Herder. For Rigol DHO800 series o-scopes Some Vesa mounts will end up blocking the rear fan from any airflow which I was not a huge fan of. You can download the STL file from the original listing below and print it at home.
About this model
For Rigol DHO800 series o-scopes Some Vesa mounts will end up blocking the rear fan from any airflow which I was not a huge fan of. These parts are to help with that as well as hold the scope probes out of the way while not in use. The Standoff part gives about 7mm of spacing between my articulating arm and the rear of the oscilloscope to allow for some air circulation. As a bonus, this gives space to include some cable management hooks for the scope probes. A second part is included to offer a mount for your scope probes when not in use. It clamps onto the rear handle with the help of 3 M3 screws. Print using TPU or the compliant part will break... What's the point of a scope on an arm if the cables end up sweeping stuff of your lab bench. I hope I've helped solve this minor issue for you…
Frequently asked questions
- Is this 3D model free to download?
- Yes. Rigol DHO800 Probe Organizer and Vesa Standoff is free to download from Thingiverse. Click the "Download free STL" button above to open the original listing.
- Where is the STL hosted?
- The download is hosted by Thingiverse, not by Thinger. We link you directly to the original listing by The_Herder.
- Who made this model?
- Designed by The_Herder, published on Thingiverse. Please credit the creator when sharing your print online.
- Can I print this at home?
- Yes. This model is intended for home FDM and resin 3D printers. Check the original listing for suggested print settings like layer height and supports.
