Lora 868MHz biquad antenna
Source: Thingiverse by f2knpw
The Lora 868MHz biquad antenna is a free printable 3D model from Thingiverse by f2knpw. This is part of my Long Range Weather Station project : I wanted to increase range for my 868 MHz lora devices. You can download the STL file from the original listing below and print it at home.
About this model
This is part of my Long Range Weather Station project : I wanted to increase range for my 868 MHz lora devices. I followed the link of this "biquad calculator" : Biquad antenna is a kind of loop antenna with a simple design, easy to build and offers a good characteristic of directivity and gain for point to point communications. It consists of two radiating elements made of connected squares with the side length equal to ¼ mid-band wavelength. I built this simple jig which can be used both for folding the 2mm coper wire, but also as a permament holder. To even increase the range I should have added a metal ground plane to reflect the back lobe to the front side. Without this ground plane my antenna acts more like an "omni" antenna. But who cares ? It works fine ! Print it in PET or PETG to…
