Customizable Square Pipe Connector - no support type(fusion360)
Source: Thingiverse by asimomagic
The Customizable Square Pipe Connector - no support type(fusion360) is a free printable 3D model from Thingiverse by asimomagic. This is a special version of the standard square pipe connector. You can download the STL file from the original listing below and print it at home.
About this model
This is a special version of the standard square pipe connector. ( To enable printing without support, the cut angle is set to 54.73561 degrees, and extra protruding parts are also cut. There are two types, "2 direction type" and "3 direction type". It can handle various pipe size. Customization is done by changing the parameters of fusion360 file (.f3d). Try this cap once. [Features] -Customizable -Fixed firmly -Hard to break even if squeezed strongly with a wrench -Easy to remove from the pipe -Easy to print(no support) [Design point] -Designed so that when the bolt is tightened, the bolt is parallel to the pipe. This enabled stable tightening. -The cutting angle of the body was determined so that three or two cut surfaces were the bottom surface of the print. [Bolt/Nut type to use] type…
Frequently asked questions
- Is this 3D model free to download?
- Yes. Customizable Square Pipe Connector - no support type(fusion360) is free to download from Thingiverse. Click the "Download free STL" button above to open the original listing.
- Where is the STL hosted?
- The download is hosted by Thingiverse, not by Thinger. We link you directly to the original listing by asimomagic.
- Who made this model?
- Designed by asimomagic, published on Thingiverse. Please credit the creator when sharing your print online.
- Can I print this at home?
- Yes. This model is intended for home FDM and resin 3D printers. Check the original listing for suggested print settings like layer height and supports.
