Ethernet pass-through patch panel
Source: Thingiverse by wdsparrow
The Ethernet pass-through patch panel is a free printable 3D model from Thingiverse by wdsparrow. Yes a pass through patch panel isn't ideal. You can download the STL file from the original listing below and print it at home.
About this model
Yes a pass through patch panel isn't ideal. It does add an extra point of failure for each cable. But for those of you who really need it here is an 8 point version that can be mounted under a shelf. Couplers purchased from Amazon, link will be provided so you can buy the same. Suggest printing with Brim of 12-14mm if you are printing in ABS with reasonable ambient temperature and minimal water absorption in the filament. The image about was printed in 11c ambient temp with Rapter PLA that hadn't had the water removed. As a result the print is pretty rough. Version 3 is shallow depth not great for tying down the ethernet cables with zip ties (image provided). But the v4 allows enough room to properly zip tie the cables but I haven't printed it yet.
Frequently asked questions
- Is this 3D model free to download?
- Yes. Ethernet pass-through patch panel is free to download from Thingiverse. Click the "Download free STL" button above to open the original listing.
- Where is the STL hosted?
- The download is hosted by Thingiverse, not by Thinger. We link you directly to the original listing by wdsparrow.
- Who made this model?
- Designed by wdsparrow, published on Thingiverse. Please credit the creator when sharing your print online.
- Can I print this at home?
- Yes. This model is intended for home FDM and resin 3D printers. Check the original listing for suggested print settings like layer height and supports.
