Electrical Switch / Outlet Junction Box
Source: MyMiniFactory by Derek Tombrello
The Electrical Switch / Outlet Junction Box is a free printable 3D model from MyMiniFactory by Derek Tombrello. I use electrical outlet junction boxes quite often as project cases when dealing with AC. You can download the STL file from the original listing below and print it at home.
About this model
I use electrical outlet junction boxes quite often as project cases when dealing with AC. It's easy to find low profile single gang boxes, but not so much triple gang boxes. I whipped this up tonight in SketchUp (yes, people do successfully use SketchUp for 3d print modeling) after a trip to my local hardware store left me empty handed. I only needed the 3-gang version, but the other two were easy enough to extract so... For my particular need, I only needed mounting holes in the bottom of the box and I needed one particular hole for the AC in line. This is a simple enough design. Using the CAD program of your choice, you can add mounting tabs or holes to suit your needs. Or, if you go with 100% infill, just drill holes as needed.
Frequently asked questions
- Is this 3D model free to download?
- Yes. Electrical Switch / Outlet Junction Box is free to download from MyMiniFactory. Click the "Download free STL" button above to open the original listing.
- Where is the STL hosted?
- The download is hosted by MyMiniFactory, not by Thinger. We link you directly to the original listing by Derek Tombrello.
- Who made this model?
- Designed by Derek Tombrello, published on MyMiniFactory. Please credit the creator when sharing your print online.
- Can I print this at home?
- Yes. This model is intended for home FDM and resin 3D printers. Check the original listing for suggested print settings like layer height and supports.
