Quick-Release Bar Clamps
Source: Thingiverse by mgx
The Quick-Release Bar Clamps is a free printable 3D model from Thingiverse by mgx. A new type of quick-release clamp designed to slide and lock on aluminum t-slot extrusion. You can download the STL file from the original listing below and print it at home.
About this model
A new type of quick-release clamp designed to slide and lock on aluminum t-slot extrusion. With this fully printable model you can build bar clamps of arbitrary size and mount multiple clamps on the same bar. Minimalist/functional by design: only two parts, both print without supports and assembles like a puzzle. The cam-lock lever mechanism is designed such that it puts slight pressure in the jaws when it locks and releases quickly with a snap then slides freely, making part switching effortless compared to classic vise/screw models. The model is fully parametric via Customizer or OpenSCAD: not only you can control the size of the clamps and their features (grooves and such) but also fit these on the most common aluminum extrusions: - Misumi 15mm/20mm (1515 or 2020) - OpenBeam - 80/20 101…
Frequently asked questions
- Is this 3D model free to download?
- Yes. Quick-Release Bar Clamps is free to download from Thingiverse. Click the "Download free STL" button above to open the original listing.
- Where is the STL hosted?
- The download is hosted by Thingiverse, not by Thinger. We link you directly to the original listing by mgx.
- Who made this model?
- Designed by mgx, published on Thingiverse. Please credit the creator when sharing your print online.
- Can I print this at home?
- Yes. This model is intended for home FDM and resin 3D printers. Check the original listing for suggested print settings like layer height and supports.
