Fillet diameter radius gauge | 22-40mm edition
Source: MakerWorld by davidmakes
The Fillet diameter radius gauge | 22-40mm edition is a free printable 3D model from MakerWorld by davidmakes. Updates23-03-04Radius measurement was incorrect due to incorrect application of the ‘decorative’ edge. You can download the STL file from the original listing below and print it at home.
About this model
Updates23-03-04Radius measurement was incorrect due to incorrect application of the ‘decorative’ edge. Resulting in a 0.7mm radius measurement error. This has now been corrected.Increased the size of text slightly on the joining ledge to enhance visibility.AboutA compact (expanded) "coaster-sized” measurement gauge to determine the inner radius/diameter of a circle/corner/curve in millimetres, ranging from 22-40mm.Built to be fully compatible/connectable with the original fillet gauges from AMT. As well as providing a larger radius size, the larger version also sports an improved connection method using ‘crush ribs’, more commonly used in injecting moulding to create perfect press-fit parts (this also reduces the likelihood of parts not fitting due to tolerance differences.For easier conne…
