2-in-1 fan duct: extruder and filament cooler for E3D V6 and others
Source: Thingiverse by eiPionezero
The 2-in-1 fan duct: extruder and filament cooler for E3D V6 and others is a free printable 3D model from Thingiverse by eiPionezero. UPDATE 21-05-2015: Updated photo renders, STL fixed, updated source file. You can download the STL file from the original listing below and print it at home.
About this model
UPDATE 21-05-2015: Updated photo renders, STL fixed, updated source file. Because I did not want to place two fans around my hotend, one for the extruder cooling and one for the filament cooling, I decided to design a double fan duct which can cool both with only one 40mm fan. Results are pretty good, all prints come out great and I have not had any filament jamming so far. I have uploaded, next to the source files (Solidworks), two STL versions. One is designed to fit on the official E3D V6 hotend, one is designed for my Chinese E3D clone. They are both the same, except for the with and height of the fan mount. The official E3D has a diameter of 22.3mm and a height of 26mm, my clone has a diameter of 25mm and a height of 32mm. To check which version you need, just measure the diameter of …
