CR-10 X Alignment Blocks
Source: Thingiverse by psdesign
The CR-10 X Alignment Blocks is a free printable 3D model from Thingiverse by psdesign. These are printable alignment blocks for leveling your X-Gantry on the CR-10 prior to leveling bed. You can download the STL file from the original listing below and print it at home.
About this model
These are printable alignment blocks for leveling your X-Gantry on the CR-10 prior to leveling bed. The long X-gantry is known to go out of level over time, whether this is due to stepper slip, roller creep, stress on axis when changing filament, what ever, it happens. A parallel axis to the base frame is crucial so when you do level your bed, the prints come out vertical and not skewed. Follow these instructions for use. (all movements from control panel unless otherwise stated) 1. Home Machine 2. Move Z up about 30 mms or more 3. Move X over about 40 mms or more 4. place alignment blocks into position on frame of machine paying attention that the left block has a cut away for the Z-stop switch. Make sure the rails of the blocks fit into the grooves in the aluminum frame. 5. Move your Z a…
Frequently asked questions
- Is this 3D model free to download?
- Yes. CR-10 X Alignment Blocks is free to download from Thingiverse. Click the "Download free STL" button above to open the original listing.
- Where is the STL hosted?
- The download is hosted by Thingiverse, not by Thinger. We link you directly to the original listing by psdesign.
- Who made this model?
- Designed by psdesign, published on Thingiverse. Please credit the creator when sharing your print online.
- Can I print this at home?
- Yes. This model is intended for home FDM and resin 3D printers. Check the original listing for suggested print settings like layer height and supports.
