RC Tank - Wheel with Planetary Gear
Source: Thingiverse by JMLin
The RC Tank - Wheel with Planetary Gear is a free printable 3D model from Thingiverse by JMLin. This is a replacement for the Drive Wheel of the RC Tank which designed by Staind. You can download the STL file from the original listing below and print it at home.
About this model
This is a replacement for the Drive Wheel of the RC Tank which designed by Staind. The gear ratio in the original design is too low if using 540 motor. Then, I found a "Speed Reduction Planetary Gear Wheel" which designed by ScorpionTDL. Its designed to reduce the speed. It has a reduction of 1:3.8. But, it's unsuited for the Staind RC Tank. So, I made some modifications. Now you can use this version on your "Staind RC Tank". You need to print the following parts: 1) Wheel with ring gear x2 2) Sun gear x2 3) Planet gear holder 1 x2 4) Planet gear holder 2 x2 5) Planet gear_13T x6 6) Baffle 1 x1 7) Baffle 2 x1 8) Baffle 3 x1 9) Baffle 4 x1 Additionally you need: M3x20 x6 M3x10 x10 M3 Nuts x10 Assembly: 1. start with the "Sun gear" 2. place the "Planet gear holder 1" on it with the small fla…
