Gear Bearing
Source: Thingiverse by emmett
The Gear Bearing is a free printable 3D model from Thingiverse by emmett. The trouble with 3D printing a ball bearing is that spheres don't adhere to the 45 degree rule, so they tend to print poorly, or if metal balls are used instead, then the bearing. You can download the STL file from the original listing below and print it at home.
About this model
The trouble with 3D printing a ball bearing is that spheres don't adhere to the 45 degree rule, so they tend to print poorly, or if metal balls are used instead, then the bearing requires assembly. This is a new kind of bearing that can only be manufactured by 3D printing and comes preassembled. It is a planetary gearset and functions like a cross between a needle bearing and a thrust bearing. No cage is required to keep the rollers in place, because their gearing keeps them perfectly spaced. The gears are all herringbone, which is why it cannot be disassembled and also why it can act as a thrust bearing. If you're wondering how well a 3D printed bearing could work under load, please check out my video: This design is fully parametric and made to be adjusted in the Customizer app to whatev…
Frequently asked questions
- Is this 3D model free to download?
- Yes. Gear Bearing is free to download from Thingiverse. Click the "Download free STL" button above to open the original listing.
- Where is the STL hosted?
- The download is hosted by Thingiverse, not by Thinger. We link you directly to the original listing by emmett.
- Who made this model?
- Designed by emmett, published on Thingiverse. Please credit the creator when sharing your print online.
- Can I print this at home?
- Yes. This model is intended for home FDM and resin 3D printers. Check the original listing for suggested print settings like layer height and supports.
