Molex Microfit 3.0 - Half of a 2x2
Source: MakerWorld by Matthew
The Molex Microfit 3.0 - Half of a 2x2 is a free printable 3D model from MakerWorld by Matthew. The Bambu X1 and P1P have a 4 pin connector on the back usually utilized for the AMS system. You can download the STL file from the original listing below and print it at home.
About this model
The Bambu X1 and P1P have a 4 pin connector on the back usually utilized for the AMS system. I don't have one but wanted to hook up some 24v lighting and a filtered air intake fan using the 4 pin connector. Not needing the other 2 pins, I took a Molex Microfit 3.0 2x2 connector and cut it in half (you can't use the 2 pin connector that is part of the microfit ecosystem because the pins have a particular shape that doesn't allow the 2 pin connector to plug into a 4 pin port). This connector isn't perfect - the pins will not click/lock in place - but it works well enough with just friction holding everything in place. Update: the .stl will likely open in Bambu Studio at 10x normal size - just scale down to 10%. Or you can use the .3mf which has the correct scaling and set for a 0.4mm nozzle…
Frequently asked questions
- Is this 3D model free to download?
- Yes. Molex Microfit 3.0 - Half of a 2x2 is free to download from MakerWorld. Open it in the free Thinger app, or use the "Download from MakerWorld" link above to open the original listing.
- Where is the STL hosted?
- The download is hosted by MakerWorld, not by Thinger. We link you directly to the original listing by Matthew.
- Who made this model?
- Designed by Matthew, published on MakerWorld. Please credit the creator when sharing your print online.
- Can I print this at home?
- Yes. This model is intended for home FDM and resin 3D printers. Check the original listing for suggested print settings like layer height and supports.
