Rigid Heddle Loom

Source: Thingiverse by ProgressTH

The Rigid Heddle Loom is a free printable 3D model from Thingiverse by ProgressTH. The frame has been designed to eliminate the number of cut PVC pipes and enhance strength and stability. You can download the STL file from the original listing below and print it at home.

Open in Thinger (free) Download from Thingiverse
QR code to download the Thinger app
On a computer? Scan with your phone to install the free app.
2,049 saves Source: Thingiverse Updated 2026-11-17 License: CC-BY · commercial OK 5 makes Category: Tools & Workshop

Tags: loom

About this model

The frame has been designed to eliminate the number of cut PVC pipes and enhance strength and stability. Only two PVC pipes run lengthwise, and the warp beam supports and heddle supports have been redesigned for the PVC to pass through them. There are 4 additional nuts and bolts used to fix the heddle supports in place and add even more stability. A diagram with dimensions has been included. Files include: Rigid Heddle Loom Parts Stick Shuttle Boat Shuttle (still in development) String Heddle Jig (uses (2x) 5mm thick bamboo chopsticks, instructions for use here: The SketchUp file is included so users can view all the pieces and modify them if necessary. This basic rigid heddle loom design incorporates 22mm diameter PVC pipe and two 3mm x 12mm bolts and accompanying hex nuts for the cogs an…
